AC1600-6 AKSA Diesel Generating Set 1600kVA Canopy Type
The AKSA AC1600-6 is a high-capacity industrial diesel generator set designed for large-scale power applications such as data centers, hospitals, industrial plants, utilities, and critical infrastructure. It is part of AKSA’s heavy-duty AC series, engineered for standby and prime power operation with continuous reliability and high load performance.
AC1600-6 AKSA Diesel Generating Set 1600kVA Canopy Type
Call for Price
- Standby Power: 1600 kVA / 1280 kW
- Prime Power: 1410 kVA / 1128 kW
- Frequency: 60 Hz
- Phase: 3-phase
- Power Factor: 0.8
- Application: Standby and Prime power
- Type: Sound attenuated canopy type
- Cummins KTA50G3 engine
- Stamford alternator
- 60 Hz, 1800 rpm operation
- Industrial heavy-duty design
- Suitable for large-scale power applications
Description
Additional Info
Reviews
Description
AC1600-6 Diesel Generator - Details and Specifications
Engine System
- Engine Type: Heavy-duty industrial diesel engine
- Typical Engine: Cummins QSK50 series (or equivalent high-output engine platform)
- Configuration: V16
- Cooling: Water-cooled radiator system
- Speed: 1800 rpm
- Aspiration: Turbocharged and aftercooled
- Fuel System: Direct injection, electronic control
Alternator System
- Type: Brushless synchronous alternator
- Insulation Class: H
- Protection Class: IP23
- Voltage Regulation: Automatic Voltage Regulator (AVR)
- Output Design: High-efficiency industrial-grade continuous load capability
Control System
- Controller: Deep Sea Electronics (DSE 7320 or equivalent AMF system)
- Functions:
- Auto Mains Failure (AMF)
- Engine protection shutdowns
- Load monitoring (kW, kVA, PF, current)
- Event logging and diagnostics
- Remote monitoring capability
Fuel & Operation
- Fuel Type: Diesel
- Consumption: High-capacity industrial range depending on load
- Duty Type: Continuous standby or prime operation
- Start System: 24V electric start
Physical Characteristics
- Canopy Type Dimensions: 354.33 × 89.37 × 100.39 in
- Dry Weight: 30,865 lb.
PRODUCT SPECIFICATIONS:
| Specification | Value |
| Model | AC1600-6 |
| Manufacturer | AKSA Power Generation |
| Type | Diesel Generator Set Sound Attenuated Canopy Type |
| Standby Power | 1600 kVA / 1280 kW |
| Prime Power | 1410 kVA / 1128 kW |
| Frequency | 60 Hz |
| Phase | 3-phase |
| Power Factor | 0.8 |
| Engine Model | Cummins QSK50 series |
| Engine Type | 16-cylinder V-type diesel |
| Engine Speed | 1800 rpm |
| Aspiration | Turbocharged and aftercooled |
| Cooling System | Water-cooled radiator system |
| Alternator Type | Brushless synchronous alternator |
| Alternator Poles | 4-pole |
| Insulation Class | Class H |
| Protection Class | IP23 |
| Voltage Regulation | Automatic Voltage Regulator AVR |
| Control System | Deep Sea Electronics DSE7320 |
| Control Functions | AMF protection monitoring diagnostics |
| Fuel Type | Diesel |
| Fuel Consumption | Varies by load industrial high-capacity range |
| Canopy Type | Sound attenuated weather protective enclosure |
| Canopy Dimensions | 354.33 × 89.37 × 100.39 in |
| Dry Weight Canopy Type | 30,865 lb |
PRODUCT RELATED DOCUMENTS:
Additional Info
| Weight | 30865 lbs |
|---|---|
| Dimensions | 354.33 × 89.37 × 100.39 in |
