Generac XG08045ANAX Protector Series (80kW)

Name: Generac XG08045ANAX Protector Series (80kW) || Brags & Hayes Generators
Brand: Single phase
SKU: XG08045ANAX

The Generac XG08045ANAX Protector Series is an 80 kW liquid-cooled gaseous standby generator engineered for dependable residential and commercial emergency backup power applications. Featuring configurable single-phase and 3-phase voltage output, a turbocharged and aftercooled 4.5L inline 4-cylinder engine, advanced Evolution controller technology, and quiet sound-attenuated operation, this generator delivers reliable standby power with premium performance and durability.

Home All generators By phases Single phase Generac XG08045ANAX Protector Series (80kW)

Share this product!

Generac XG08045ANAX Protector Series (80kW)

Call for Price

SKU: XG08045ANAX

80 kW standby power rating at 60 Hz

Single-phase and configurable 3-phase voltage capability

120/240V single-phase output

208/120V, 240/120V, and 480/277V 3-phase configurable outputs

Liquid-cooled 4.5L inline 4-cylinder turbocharged and aftercooled engine

Operates on Natural Gas or Liquid Propane Vapor

Field convertible fuel type with no mechanical adjustment required

Two-Line LCD multilingual Evolution controller with external viewing window

Isochronous electronic governor

±1% electronic voltage regulation

High motor-starting and surge capability

Mobile Link connectivity available

Quiet sound-attenuated enclosure

Corrosion-resistant aluminum enclosure

Closed coolant recovery system

Smart battery charger included

UV/Ozone resistant hoses

UL 2200 Listed

EPA emissions compliant

CA & MA emissions compliant

5 Year limited warranty

Description

XG08045ANAX product details and specifications:

General Details

Model: XG08045ANAX

Series: Protector® Series

Standby Power Rating: 80 kW

Frequency: 60 Hz

Generator Type: Liquid-Cooled Gaseous Engine Standby Generator

Single-Phase and Configurable 3-Phase Output

EPA Emissions Compliant

CA / MA Emissions Compliant

UL 2200 Listed

SwRI Listed and Labeled

5 Year Limited Warranty

Engine Specifications

Engine Make: Generac

Engine Configuration: Inline 4 Cylinder

Engine Displacement: 4.5 L

Turbocharged and Aftercooled Intake Air System

Compression Ratio: 8.85:1

Lifter Type: Hydraulic

Oil Pump Type: Gear

Oil Filter Type: Full Flow Spin-On Cartridge

Crankcase Capacity: 12 qt / 11 L

Governor Type: Electronic Isochronous

Steady State Regulation: ±0.25%

Fuel System

Fuel Type: Natural Gas or Liquid Propane Vapor

Field Convertible Fuel System

No Mechanical Adjustment Required for Fuel Conversion

LP Fuel Pressure: 7–14 in Water Column

NG Fuel Pressure: 3.5–14 in Water Column

Fuel Efficient Operation

Cooling System

Cooling Type: Ethylene Glycol 50/50 Mix

Water Pump: Belt-Driven

Fan Speed: 2,100 RPM

Fan Diameter: 22 inches

Fan Mode: Pusher

Closed Coolant Recovery System

Generator Specifications

120/240V Single-Phase Output

120/208V 3-Phase Output

120/240V 3-Phase Output

277/480V 3-Phase Output

Alternator Type: Synchronous

Rotor Insulation Class: H

Stator Insulation Class: H

Telephone Interference Factor (TIF): <50

Direct Brushless Excitation System

Voltage Regulation: ±1%

Less than 5% Total Harmonic Distortion

Electrical System

12 Volt System Voltage

12 Volt 35 Amp Battery Charge Alternator

2.5 Amp Static Battery Charger

Recommended Battery: Group 27F, 725 CCA

Electronic Isochronous Governor

Control System

Evolution™ Controller

Two-Line LCD Multilingual Display

External Viewing Window for Generator Status

Mobile Link® Connectivity Capability

Automatic Utility Voltage Sensing

Programmable 7-Day Exerciser

Integrated Smart Battery Charger

Over/Under Voltage Protection

50 Event Run Log

Failure to Transfer Protection

Low Battery Protection

Performance Features

Quiet-Test™ Operation

High Motor-Starting Capability

Superior Surge Handling

Reliable Emergency Standby Power

Designed for Sensitive Electronic Equipment

Quiet Sound Attenuated Enclosure

Prototype Tested Design

Enclosure Features

Corrosion Resistant Aluminum Enclosure

Sound Attenuated Weather Protective Enclosure

Electrostatically Applied Textured Epoxy Paint

Enclosed Critical Grade Muffler

UV/Ozone Resistant Hoses

Compact Installation Design

Dimensions and Weight

Overall Length: 127 inches

Overall Width: 54 inches

Overall Height: 49 inches

Genset Only Weight: 2597 lbs.

Shipping Weight: 2825 lbs.

product specifications:

Specification	Value
Model	XG08045ANAX
Series	Protector® Series
Standby Power Rating	80 kW
Frequency	60 Hz
Phase	Single-Phase / Three-Phase
Voltage Output	120/240V 1-Phase; 120/208V, 120/240V, or 277/480V 3-Phase
Generator Type	Liquid-Cooled Gaseous Engine Standby Generator
Fuel Type	Natural Gas / Propane Vapor
Fuel Type Conversion	Field Convertible with No Mechanical Adjustment Required
LP Fuel Pressure	7–14 in Water Column
NG Fuel Pressure	3.5–14 in Water Column
120/240V 1-Phase Output	80 kW / 333 A
120/208V 3-Phase Output	80 kW / 278 A
120/240V 3-Phase Output	80 kW / 241 A
277/480V 3-Phase Output	80 kW / 120 A
Alternator Type	Synchronous
Rotor Insulation Class	H
Stator Insulation Class	H
Telephone Interference Factor (TIF)	<50
Alternator Output Leads 1-Phase	4 wire
Alternator Output Leads 3-Phase	6 wire
Bearings	Sealed Ball
Coupling	Flexible Disc
Excitation System	Direct Brushless
Voltage Regulation	±1%
Voltage Regulation Type	Electronic
Governor Type	Electronic Isochronous
Steady State Regulation	±0.25%
Engine Make	Generac
Engine Model	Inline 4 Cylinder
Displacement	4.5 L
Compression Ratio	8.85:1
Intake Air System	Turbocharged and Aftercooled
Lifter Type	Hydraulic
Oil Pump Type	Gear
Oil Filter Type	Full Flow Spin-On Cartridge
Crankcase Capacity	12 qt / 11 L
Cooling Type	Ethylene Glycol 50/50 Mix
Water Pump	Belt-Driven
Fan Speed	2,100 RPM
Fan Diameter	22 inches
Fan Mode	Pusher
Battery Charge Alternator	12 Volt 35 Amp
Static Battery Charger	2.5 Amp
Recommended Battery	Group 27F, 725 CCA
System Voltage	12 Volts
Sound Output	68 dB(A) at 23 ft
Mobile Link Connectivity	Available
Controller	Evolution™ Controller
Enclosure Material	Aluminum
Enclosure Type	Sound Attenuated Weather Protective Enclosure
Certification	UL 2200 Listed
Emissions Compliance	EPA / CA / MA Compliant
Warranty	5 Year Limited Warranty
Overall Length	127 inches
Overall Width	54 inches
Overall Height	49 inches
Genset Only Weight	2597 lbs.
Shipping Weight	2825 lbs.
