C80D6 - Details & Specifications:

General

• Model: C80D6

• Model Number: A063P967

• Standby Rating: 80 kW / 80 kVA (60 Hz)

• Fuel Tank: 24 Hr. sub-base tank (260 gal usable volume)

• Voltage - Phase: 120/240V, 1 Phase

Engine Specifications

• Engine: Cummins QSB5

• Displacement: 4.5 L (272 in³)

• Cylinder Block: Cast iron, in-line

• Rated Speed: 1800 rpm

• Battery Capacity (at 0°C/32°F): 2 x 850 amps

• Battery Charging Alternator: 100 amps

• Starting Voltage: 2 x 12-volt, negative ground

• Lube Oil Filter Type: Spin-on with relief valve

• Fuel Consumption - 50% Load: 4.00 gph

• Fuel Consumption - 100% Load: 7.30 gph

Alternator Specifications

• Design: Brushless, 4-pole, drip-proof, revolving field

• Stator: 2/3 pitch

• Rotor: Direct coupled, flexible disc

• Insulation System: Class H per NEMA MG1-1.65

• Standard Temp. Rise: 120°C (248°F) Standby

• Exciter Type: Torque match (shunt), with PMG as option

• Alternator Cooling: Direct drive centrifugal blower

• AC Waveform (THDV): < 5% no load to full linear load, < 3% for any single harmonic

• Telephone Influence Factor (TIF): < 50 per NEMA MG1-22.43

• Telephone Harmonic Factor (THF): < 3%

Control System

• Controller: PowerCommand 1.1 electronic control

• Automatic remote starting/stopping

• Precise frequency and voltage regulation

• Alarm and status message display

• Output metering with auto-shutdown at fault detection

• Governor Regulation Class: ISO 8528 Part 1 Class G3

• Voltage Regulation (no load to full load): ± 1.0%

• Random Voltage Variation: ± 1.0%

• Frequency Regulation: Isochronous

• Random Frequency Variation: ± 0.5%

Electrical

• Circuit Breaker: 400 Amps (adjustable)

• Battery Charger: Standard - 6A

• Radio Frequency Emissions Compliance: FCC Title 47 Part 15, Class A and B

Enclosure

• Type: Sound Level 1, Sandstone

• Material: Aluminum with durable powder-coat paint finish

• Sound Level: 74.6 dB(A) at 23 ft (7 m), full rated load

• Wind Load Rating: 180 mph per ASCE 7-10

Operating Environment

• Operating Temp. Range: -40°F to +122°F (-40°C to +50°C)

• Coolant heaters standard for cold-weather starting

Dimensions & Weight (with 24-hr fuel tank)

• Length: 119 in.

• Width: 40 in.

• Height: 83 in.

• Dry Weight: 3,309 lbs.

• Wet Weight: 3,425 lbs.

Certifications & Codes

• Designed and manufactured in facilities certified to ISO 9001 / ISO 9002

• UL 2200 Listed - Stationary Engine Generator Assemblies

• Meets Prototype Test Support (PTS) requirements of NFPA 110 for Level 1 systems

• Engine certified to U.S. EPA SI Stationary Emission Regulation, 40 CFR Part 60

Warranty

• 2-year base warranty when used in EPA-Stationary Emergency application

• Extended warranty options available through Cummins dealers
