Generac Guardian Series Standby Generator – Model G007171-0 (10 kW)

Name: Generac Guardian Series Standby Generator – Model G007171-0 (10 kW) || Brags & Hayes Generators - Español
Brand: NFPA 110 Level 1

The Generac Guardian Series 10 kW standby generator (Model G007171-0) is a compact air-cooled residential backup power solution designed to automatically restore power during utility outages. Powered by the Generac G-Force 400 Series engine and equipped with Evolution™ controls and standard Wi‑Fi® connectivity, it delivers reliable and stable backup power for essential home systems and sensitive electronics.

Home Todos los generadores Por estándar NFPA 110 Level 1 Generac Guardian Series Standby Generator – Model G007171-0 (10 kW)

Share this product!

Generac Guardian Series Standby Generator – Model G007171-0 (10 kW)

Call for Price

10 kW standby power on liquid propane, 9 kW on natural gas

True Power™ Technology with less than 5% total harmonic distortion

Two-line multilingual LCD Evolution™ controller

Standard Wi‑Fi® connectivity with Mobile Link® support

Generac G-Force 400 Series engine with 460cc displacement

Automatic voltage regulation with ±1% accuracy

Electronic governor for stable 60 Hz operation

Quiet-Test™ low-speed exercise mode

Operates on natural gas or liquid propane

Sound-attenuated aluminum enclosure for quiet operation

Flexible fuel line connector included

5-year limited warranty

Descripción

G007171-0 (10 kW) product details and specifications:

General Details

Type: Air-cooled residential standby generator

Series: Generac Guardian® Series

Frequency: 60 Hz

Phase: Single-phase

Fuel Type: Natural Gas or Liquid Propane

Warranty: 5-Year Limited

Engine Specifications

Engine Model: Generac G-Force 400 Series

Cylinders: 1

Displacement: 460 cc

Cylinder Block: Aluminum with cast iron sleeve

Valve Arrangement: Overhead valve

Lifter Type: Solid

Ignition System: Solid-state with magneto

Governor System: Electronic

Compression Ratio: 9.5:1

Starter: 12 VDC

Oil Capacity: Approx. 1.1 qt

Operating RPM: 3600

Generator Specifications

Rated Power (LP): 10 kW

Rated Power (NG): 9 kW

Voltage: 240 V

Max Load Current: 41.7 A (LP) / 37.5 A (NG)

Total Harmonic Distortion: Less than 5%

Circuit Breaker: 45 Amp

Power Factor: 1.0

Rotor Poles: 2

Control System

Controller: Evolution™ multilingual LCD controller

Modes: AUTO / MANUAL / OFF

Features: Utility voltage sensing, programmable exercise, smart battery charger, maintenance and event logs

Dimensions and Weight

Dimensions (L x W x H): 48 x 25 x 29 inches

Weight: 338 lbs

Sound Levels

Normal Operation: 61 dB(A) at 23 ft

Quiet-Test Mode: 57 dB(A)

Fuel Consumption

Natural Gas (Full Load): 127 ft³/hr

Liquid Propane (Full Load): 54 ft³/hr

product specifications:

Category	Value
Model	G007171-0
SKU	7171
Power Output (LP)	10 kW
Power Output (NG)	9 kW
Voltage	240 V
Frequency	60 Hz
Phase	Single
Max Current (LP)	41.7 A
Max Current (NG)	37.5 A
THD	<5%
Circuit Breaker	45 A
Power Factor	1.0
Engine	Generac G-Force 400 Series
Cylinders	1
Displacement	460 cc
RPM	3600
Fuel Type	Natural Gas / Liquid Propane
Dimensions (L x W x H)	48 x 25 x 29 inches
Weight	338 lbs
Sound Level	61 dB(A)
Quiet Mode Sound	57 dB(A)
Oil Capacity	1.1 qt
Warranty	5 years
